5285/CBC
₹43 - ₹45.05 Lakh
Ex-showroom price

CAB/5580
₹50.92 Lakh
Ex-showroom price
Instead of counting features, we compare which ones each vehicle actually includes.
| Fuel Tank (Litres) | 315 Ltr | 300 Ltr |
| Engine | VEDX8, OBDII | CUMMINS ISBe 5.6L |
| Fuel Type | Diesel | Diesel |
| Emission Norms | BS-VI | BS-VI |
| Max Torque | 1000 Nm | 850 Nm |
| Mileage | 2.5-3.5 kmpl | 2.5-3.5 kmpl |
| Max Speed (km/h) | 80 | 80 |
| Engine Cylinders | 6 | 6 |
| Turning Radius (mm) | 18600 | 9800 |
| Battery Capacity | 120 Ah | 120 Ah |
| Product Type | L5N (High Speed Goods Carrier) | L5N (High Speed Goods Carrier) |
| Carrier Type | Goods Carrier | Goods Carrier |
| Max Power | 194 kW | 220 Hp |
| Engine Displacement (cc) | 7698 cc | 5635 cc |
| Mileage Highway | 3-4 | |
| Gradeability (%) | 39 % |
| Overall Length (mm) | 8345 | 8571 |
| Overall Width (mm) | 2570 | 2510 |
| Overall Height (mm) | 2960 | 2961 |
| Ground Clearance (mm) | 252 | 230 |
| Wheelbase (mm) | 5285 | 5580 |
| Axle Configuration | 8x4 | 8x4 |
| Size (Cu. M) | 20 m3 Box |
| Transmission | Manual | Manual |
| Payload (Kgs) | 25000 Kgs | 26000 Kgs |
| GVW / GCW (Kgs) | 35000 kg | 35000 kg |
| Kerb Weight (Kgs) | 10000 | 9000 |
| Gear Box | ET140S9, 9 Forward + 1 Reverse | G1150 9 speed Gearbox with crawler & one reverse |
| Power Steering | Yes | Yes |
| Clutch | 430 mm, pull type, Single dry plate | 380 mm Dia Push type Single Plate Dry FrictionOrganic Lining |
| Steering | Power Steering | Power Steering |
| A/C | HVAC (Optional) | Optional |
| Cruise Control | Yes | No |
| Navigation System | No | No |
| Telematics | Yes | Yes |
| Tiltable Steering | Tilt and telescopic | Tilt and telescopic |
| Arm-rest | No | No |
| Seat Type | Standard | Standard |
| Driver Information Display | Yes | Yes |
| Adjustable Driver Seat | Yes | 6 way adjustable |
| Seating Capacity | D+1 | D+1 |
| Tubeless Tyres | Optional | No |
| Seat Belts | Yes | Yes |
| Hill Hold | No | No |
| Brakes | S-Cam Dual Line with ABS | New iCGT Brakes |
| Front Suspension | Parabolic suspension | Parabolic Leaf Spring |
| Rear Suspension | Bogie Suspension | Semi Elliptical Leaf Spring |
| ABS | Yes | Yes |
| Parking Brakes | Pnuematically operated hand-control valve | Yes |
| Front Axle | Forged reverse elliot type with anti-roll bar | Forged I beam reverse elliot type - drop beam |
| Rear Axle | Single reduction tandem axle with interaxle lock and anti-roll bar | Single reduction, extra heavy duty, hypoid gears, fully floating axle shafts with differential lock |
| Chassis Type | Chassis with Cowl | Chassis with Cabin |
| Body Option | Customizable body | Box body |
| Cabin Type | Day Cabin | Day Cabin |
| Tiltable Cabin | Hydraulically tiltable | Hydraulically tiltable |
| Number of Tyre | 12 | 12 |
| Rear Tyre | 8.0x20 (Radial) | 295/90 R20 |
| Front Tyre | 8.0x20 (Radial) | 295/90 R20 |
| Chassis | Yes | Yes |
| Battery(Volts) | 24V | 12 V |
| Fog Lights | Provision | No |
