Specifications

Tata LPT 4825

Explore Tata LPT 4825 specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

LPT 4825

Specifications & Features.

Key Specifications

Fuel TypeDiesel
EngineCummins ISBe 6.7L
TransmissionManual
Power249 hp

Performance

Fuel Tank (Litres)365 Ltr
EngineCummins ISBe 6.7L
Fuel TypeDiesel
Emission NormsBS VI
Max Torque950 Nm
Mileage3.5 kmpl
Max Speed (km/h)80
Engine Cylinders6

Dimension

Overall Width (mm)2500
Ground Clearance (mm)250
Wheelbase (mm)6800
Axle Configuration10x2
Loading Length {mm}9144

Transmission & Loading Capacity

TransmissionManual
Payload (Kgs)38000 Kgs
GVW / GCW (Kgs)47500 kg
Kerb Weight (Kgs)9500
Gear Box9 Forward + 1 Reverse
Power SteeringYes
Clutch430 mm dia push type single plate dry friction organic lining

Features

SteeringPower Steering
A/CNo
Cruise ControlNo
Navigation SystemNo
TelematicsNo
Tiltable SteeringNo
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesAir Brake
Front SuspensionParabolic Leaf Spring
Rear SuspensionSemi elliptic leaf spring with Bell crank mechanism
ABSNo
Parking BrakesYes
Front AxleTATA heavy duty 7T reverse elliot type
Rear AxleTATA Single reduction RA110HD

Body Option & Cabin Type

Chassis TypeChassis with Face Cowl
Body OptionCustomizable body
Cabin TypeDay Cabin
Tiltable CabinNo

Tyres

Number of Tyre16
Rear Tyre295/90R20
Front Tyre295/90R20

Others

ChassisYes
Battery(Volts)12 V
Fog LightsNo

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
