Specifications

Switch IeV3

Explore Switch IeV3 specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

IeV3

Specifications & Features.

Key Specifications

Fuel TypeElectric
Engine-
TransmissionAutomatic
Power40 kW

Performance

Fuel TypeElectric
Emission NormsZERO Emission
Max Torque190 Nm
Max Speed (km/h)70
Battery Capacity25.6 kWh
Product TypeL3N (Low Speed Goods Carrier)
Carrier TypeGoods Carrier
Max Power40 kW

Dimension

Ground Clearance (mm)177
Wheelbase (mm)2510
Axle Configuration4x2
Loading Length {mm}2645
Loading Width {mm}1620
Loading Height {mm}440

Transmission & Loading Capacity

TransmissionAutomatic
Payload (Kgs)1250 Kgs
GVW / GCW (Kgs)2590 kg
Kerb Weight (Kgs)1340
Gear BoxSingle speed gearbox
Power SteeringYes

Features

SteeringElectric Power Steering
A/CNo
Cruise ControlNo
Navigation SystemNo
TelematicsYes
Tiltable SteeringYes
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesDisc & Drum Brakes
Front SuspensionRigid Suspension
Rear SuspensionRigid Suspension
ABSYes
Parking BrakesYes

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionDeck Body
Cabin TypeDay Cabin
Tiltable CabinYes

Tyres

Number of Tyre4
Rear Tyre185 R14 LT 8 PR, Radial
Front Tyre185 R14 LT 8 PR, Radial

Others

ChassisYes
Battery(Volts)300 V
Fog LightsNo

Charging

Charging Time3-4 Hrs

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
