Specifications

BharatBenz 4228RT

Explore BharatBenz 4228RT specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

4228RT

Specifications & Features.

Key Specifications

Fuel TypeDiesel
Engine0M 926
TransmissionManual
Power210 kW

Performance

Fuel Tank (Litres)330/310 Ltr
Engine0M 926
Fuel TypeDiesel
Emission NormsBS VI-OBD-2
Max Torque1100 Nm
Mileage2.25-3.25 kmpl
Max Speed (km/h)60
Engine Cylinders6

Dimension

Overall Length (mm)9635
Overall Width (mm)2490
Overall Height (mm)2955
Ground Clearance (mm)247
Wheelbase (mm)6575
Axle Configuration10x4

Transmission & Loading Capacity

TransmissionManual
Payload (Kgs)31250 Kgs
GVW / GCW (Kgs)42000 kg
Kerb Weight (Kgs)10750
Gear BoxG131, 9F+1R, Mechanical, Synchromesh Gears
Power SteeringYes
Clutch395, 3.5 mm Dia, Single plate, Dry type

Features

SteeringHydraulic Power assisted
A/CYes
Cruise ControlNo
Navigation SystemNo
TelematicsNo
Tiltable SteeringTilt & Telescopic
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesPneumatic, Foot Operated, Dual Line Drum Brakes
Front SuspensionParabolic
Rear SuspensionBalancer
ABSYes
Parking BrakesPneumatically operated hand control valve
Front AxleIF 7.0
Rear AxleIRT390-11, Single Tyre Lift Axle

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionDeck Body
Cabin TypeSleeper Cabin
Tiltable CabinYes

Tyres

Number of Tyre16
Rear Tyre295/90R20
Front Tyre295/90R20

Others

ChassisYes
Battery(Volts)24 V
Fog LightsNo

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
