Specifications

Piaggio Ape Wave

Explore Piaggio Ape Wave specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

Ape Wave

Specifications & Features.

Key Specifications

Fuel TypeElectric
Engine-
TransmissionAutomatic
Power4.3 kW

Performance

Max Power4.3 kW
Fuel TypeElectric
Gradeability (%)19.6 %
Max Speed (km/h)45
Range140
Battery Capacity5.4 kWh
Product TypeL5M (High Speed Passenger Carrier)
Carrier TypePassenger Carrier

Charging

Charging Time3 Hrs 20 mins

Dimension

Overall Length (mm)2752
Overall Width (mm)1370
Overall Height (mm)1780
Ground Clearance (mm)225
Wheelbase (mm)1920

Transmission & Loading Capacity

TransmissionAutomatic
Kerb Weight (Kgs)395
Power SteeringNo
GVW / GCW (Kgs)695 kg
Gear Box1 Forward + 1 Reverse

Features

SteeringHandle bar type
A/CNo
Cruise ControlNo
Navigation SystemNo
TelematicsYes
Tiltable SteeringNo
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesDrum brakes hydraulically actuated internal expanding type, self adjusting
Front SuspensionLeading arm, constant rate coil spring, hydraulic damper and helical compression with Spring
Rear SuspensionSemi trailing arm, rubber compression spring with hydraulic damper

Body Option & Cabin Type

Vehicle TypeAuto Rickshaw
Chassis TypeChassis with Cabin
Body OptionFully Built
Cabin TypeDay Cabin
Tiltable CabinNo

Tyres

Number of Tyre3
Rear Tyre120/80 R12, Radial
Front Tyre120/80 R12, Radial

Others

ChassisYes
Battery(Volts)51.2 V
Fog LightsNo

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
