Specifications

Jangid LDR Cargo Plus

Explore Jangid LDR Cargo Plus specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

LDR Cargo Plus

Specifications & Features.

Key Specifications

Fuel TypeElectric
Engine-
TransmissionAutomatic
Power1 hp

Performance

Max Power1 hp
Fuel TypeElectric
Gradeability (%)20 %
Max Speed (km/h)23
Turning Radius (mm)2800
Range120
Battery Capacity120 Ah
Product TypeL3N (Low Speed Goods Carrier)

Charging

Charging Time4-5 Hour

Dimension

Overall Length (mm)2776
Overall Width (mm)998
Overall Height (mm)1788
Ground Clearance (mm)250
Wheelbase (mm)2125
Axle Configuration3x3

Transmission & Loading Capacity

TransmissionAutomatic
Kerb Weight (Kgs)380
Power SteeringNo
GVW / GCW (Kgs)500 kg
Gear Box1 Forward + 1 Reverse
Payload (Kgs)350 Kgs

Features

SteeringHandle bar type
A/CNo
Cruise ControlNo
Navigation SystemNo
TelematicsNo
Tiltable SteeringNo
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesDrum Brakes
Front SuspensionLeaf spring suspension
Rear SuspensionLeaf Spring Suspension
Parking BrakesYes
ABSNo

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionDeck Body
Cabin TypeDay Cabin
Tiltable CabinNo

Tyres

Number of Tyre3
Rear Tyre3.75 x 12
Front Tyre3.75 x 12

Others

ChassisYes
Battery(Volts)48 V
Fog LightsNo
Loading Platform Area(Sq.ft)112

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
