Specifications

ADM E-Storm

Explore ADM E-Storm specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

E-Storm

Specifications & Features.

Key Specifications

Fuel TypeElectric
Engine-
TransmissionAutomatic
Power1 hp

Performance

Max Power1 hp
Fuel TypeElectric
Gradeability (%)20 %
Max Speed (km/h)25
Turning Radius (mm)3800
Range80-90
Battery Capacity48 Kwh
Product TypeL3M (Low Speed Passenger Carrier)

Charging

Charging Time8-9 hours

Dimension

Overall Length (mm)2780
Overall Width (mm)980
Overall Height (mm)1770
Ground Clearance (mm)200
Wheelbase (mm)2160
Axle Configuration3x3

Transmission & Loading Capacity

TransmissionAutomatic
Power SteeringNo
GVW / GCW (Kgs)700 kg
Gear Box1 Forward + 1 Reverse

Features

SteeringHandle bar type
A/CNo
Cruise ControlNo
Navigation SystemNo
TelematicsNo
Tiltable SteeringNo
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesLever & Paddle Operated, Drum Type
Front Suspension43mm Telescopic Hydraulic
Rear SuspensionLeaf Spring Shocker
Parking BrakesMechanical Hand Lever Operated
ABSNo

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionFully Built
Cabin TypeDay Cabin
Tiltable CabinNo

Tyres

Number of Tyre3
Rear Tyre3.75-12
Front Tyre3.75-12

Others

ChassisYes
Battery(Volts)48 V
Fog LightsNo

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
