Specifications

3evi E30X

Explore 3evi E30X specifications & features across all variants — engine, dimensions, safety and more.

Price on Request

Ex-showroom Price

E30X

Specifications & Features.

Key Specifications

Fuel TypeElectric
Engine-
TransmissionGear Differential
Power4 Hp

Performance

Max Power4 Hp
Fuel TypeElectric
Gradeability (%)20 %
Turning Radius (mm)3900
Range130
Battery Capacity200 Ah
Product TypeL5N (High Speed Goods Carrier)
Carrier TypeGoods Carrier

Charging

Charging Time6-7 hours

Dimension

Overall Length (mm)3145
Overall Width (mm)1490
Overall Height (mm)1770
Ground Clearance (mm)245
Wheelbase (mm)2100
Axle Configuration3x3
Loading Width {mm}1400
Loading Length {mm}1500

Transmission & Loading Capacity

TransmissionGear Differential
Kerb Weight (Kgs)526
Power SteeringNo
GVW / GCW (Kgs)1085 kg
Gear Box1 Forward + 1 Reverse
Payload (Kgs)559 Kgs

Features

SteeringHandle bar type
A/CNo
Cruise ControlNo
Navigation SystemYes
TelematicsNo
Tiltable SteeringNo
Arm-restNo
Seat TypeStandard

Brakes & Suspension

BrakesDrum Brakes
Front SuspensionMacPherson strut suspension
Rear SuspensionSemi-trailing suspension
Parking BrakesYes
ABSNo

Body Option & Cabin Type

Chassis TypeChassis with Cabin
Body OptionDeck Body
Cabin TypeDay Cabin
Tiltable CabinNo

Tyres

Number of Tyre3
Rear Tyre3.75-12
Front Tyre4.50-10

Others

ChassisYes
Battery(Volts)48V
Fog LightsNo

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
