3160/CBC
₹26.88 Lakh
Ex-showroom price

4570/Box Body
₹32.6 Lakh
Ex-showroom price
Instead of counting features, we compare which ones each vehicle actually includes.
| Fuel Tank (Litres) | 171/160 Ltr | 365 Ltr |
| Engine | 4D34i | CUMMINS ISLe 400, Water cooled, direct injection, turbocharged diesel engine |
| Fuel Type | Diesel | Diesel |
| Emission Norms | Bharat Stage VI - OBD-2 | E-V |
| Max Torque | 520 Nm | |
| Mileage | 4.5-5.5 kmpl | 2.5-3.5 kmpl |
| Max Speed (km/h) | 60 | 95 |
| Engine Cylinders | 4 | 6 |
| Turning Radius (mm) | 12200 | 9175 |
| Battery Capacity | 75 Ah | |
| Product Type | L5N (High Speed Goods Carrier) | |
| Carrier Type | Goods Carrier | |
| Max Power | 125 kW | 400 Hp |
| Engine Displacement (cc) | 3907 cc | 8900 cc |
| Mileage City | 3.5-4.5 | |
| Gradeability (%) | 38.7 % | 40/65 % |
| Torque | 1700 Nm |
| Overall Length (mm) | 5435 | 8038 |
| Overall Width (mm) | 2135 | 2590 |
| Overall Height (mm) | 2420 | 3219 |
| Ground Clearance (mm) | 245 | 353 |
| Wheelbase (mm) | 3160 | 4570 |
| Axle Configuration | 4x2 | 6x4 |
| Size (Cu. M) | 6.5 |
| Transmission | Manual | Manual |
| Payload (Kgs) | 7250 Kgs | |
| GVW / GCW (Kgs) | 13000 kg | 40000 kg |
| Kerb Weight (Kgs) | 5750 | 10200 |
| Gear Box | Improved G85, 6F+1R, Mechanical, Synchromesh Gears | ZF 16S 1935 TD LHD GEN 4 with PTO |
| Power Steering | Yes | Yes |
| Clutch | 362 mm Single dry plate, hydraulic control | 430 dia |
| Steering | Hydraulic Power assisted | Integral Hydraulic Power Assisted Steering |
| A/C | HVAC (Optional) | |
| Cruise Control | No | |
| Navigation System | No | |
| Telematics | Yes | |
| Tiltable Steering | Tilt and telescopic | Tilt & Telescopic |
| Arm-rest | No | |
| Seat Type | Standard | Standard |
| Driver Information Display | Yes | |
| Adjustable Driver Seat | 4 way adjustable | Yes |
| Seating Capacity | D+1 | D+2 |
| Tubeless Tyres | No | |
| Seat Belts | Yes | Yes |
| Hill Hold | No |
| Brakes | Pneumatic, Foot Operated, Dual Line Brakes | Full Air Dual circuit - S Cam with ABS Auxillary Brake - Engine exhaust brake |
| Front Suspension | Semi elliptic leaf spring with hydraulic shock absorbers | Parabolic Leaf Spring |
| Rear Suspension | Semi Elliptic laminated Leaf Spring | Two spring balance beam Bogie with semi elliptic multi rubber Mounted Torque Rods & V-rod |
| ABS | Yes | Yes |
| Parking Brakes | Spring Actuated with Hand Brake Valve | |
| Front Axle | IF 5.0 | |
| Rear Axle | Dana S 145 | TATA RA 109 |
| Chassis Type | Chassis with Cabin | Chassis with Cabin |
| Body Option | Customizable body | Box body |
| Cabin Type | Day Cabin | HVAC, Prima Cabin |
| Tiltable Cabin | Yes | Yes |
| Number of Tyre | 6 | 10 |
| Rear Tyre | 8.25x20, Nylon | 12R24 -18PR |
| Front Tyre | 8.25x20, Nylon | 12R24 -18PR |
| Chassis | Yes | Yes |
| Battery(Volts) | 24V | |
| Fog Lights | No |

Price on Request*
Ex-showroom Price
